链号
节距
滚子外径(最大)
内链节内宽（最小）
排距
销轴直径
内链板高度
链条通道高度
抗拉载荷
重量
单排
双排
三排
P
d1(min)
b1(min)
Pt
d2(min)
h2
h1(min)
Q
q
in
mm
KN
kg/m
06B
3/8"
9.525
6.35
5.72
10.24
3.28
8.26
8.52
8.90
16.90
24.90
0.4
08B
1/2"
12.70
8.51
7.75
13.92
4.45
11.81
12.07
17.80
31.10
44.50
0.7
10B
5/8"
15.875
10.16
9.65
16.59
5.08
14.73
14.99
22.20
66.70
0.95
12B
3/4"
19.05
11.68
19.46
16.13
16.39
28.90
57.80
86.70
1.25
16B
1"
25.40
15.88
17.02
31.88
8.28
21.08
21.34
60.00
106.00
160.00
2.7
20B
1.1/4"
31.75
19.56
36.45
10.19
26.42
26.68
95.00
170.00
250.00
3.6
24B
1.1/2"
38.10
48.36
14.63
33.4
33.73
280.00
425.00
6.7
28B
1.3/4"
44.45
27.94
30.99
59.56
15.9
37.08
37.46
200.00
360.00
530.00
8.3
32B
2"
50.80
29.21
58.55
17.81
42.29
42.72
450.00
670.00
10.5
40B
2.1/2"
63.50
39.37
72.29
22.89
52.96
53.49
355.00
630.00
950.00
16
48B
3"
76.20
48.26
45.72
91.21
29.24
63.88
64.52
560.00
1000.00
1500.00
25
56B
3.1/2"
88.90
53.98
53.34
106.60
34.32
77.85
78.64
850.00
1600.00
2240.00
35
64B
4"
101.6
63.5
60.96
119.89
39.4
90.17
91.08
1120.00
2000.00
3000.00
60
